Dell E2020H 20" 16:9 TN Monitor - Manual (Page 12)

12 │ About your monitor
Monitor specifications
Model E1920H E2020H
Screen type Active matrix-TFT LCD Active matrix-TFT LCD
Panel type TN TN
Viewable area
Diagonal
470.10 mm (18.5 in.) 494.1 mm (19.5 in.)
Active area
Horizontal
Vertical
Area
409.80 mm (16.13in.)
230.40 mm (9.07in.)
944.18 cm² (146.30 in.²)
432.96 +/- 0.96mm (17.05 in.)
238.05 +/- 1.71mm (9.37 in.)
1025.53 cm² ~ 1030.76 cm²
(158.96 in.² ~ 160.55 in.²)
Pixel pitch 0.3000 mm x 0.3000 mm 0.2700 mm x 0.2700 mm
Pixel per inch (PPI) 85 94
Viewing angle
Horizontal
Vertical
90° (typical)
65° (typical) 170° (typical)
160° (typical)
Brightness 250 cd/m² (typical) 250 cd/m² (typical)
Contrast ratio 600 to 1 (typical) 1,000 to 1 (typical)
Faceplate coating Anti-glare with 3H hardness Anti-glare with 3H hardness
Backlight LED light bar system LED light bar system
Response time
Normal mode
Fast mode
5 ms
- 5 ms
-
Color depth 16.7 million colors 16.7 million colors
Color gamut 72% (CIE1931)/83%(CIE1976) 72% (CIE1931)/83%(CIE1976)
Dell display manager
compatibility Yes Yes
Connectivity 1 x DP1.2, 1 x VGA 1 x DP1.2, 1 x VGA
Bezel width (edge of
monitor to active area) 17.8 mm (Top)
17.8 mm (Left/Right)
17.8 mm (Bottom) 18.3 +/- 0.5 mm (Top)
18.3 +/- 0.5 mm (Left/Right)
18.3 +/- 0.5 mm (Bottom)
Security Security-lock slot for cable
lock (optional purchase) Security-lock slot for cable
lock (optional purchase)
Tilt angle -5° to 21° -5° to 21°
Height adjustable stand - -
Built-in Speakers
(2 x 1 W sound output)
- -
