Dell E2020H 20" 16:9 TN Monitor - Manual (Page 17)

About your monitor │ 17
Electrical specifications
Model E1920H
Video input signals • Analog RGB: 0.7 V ± 5 %,
75 Ω input impedance
• DP, 600 mV
for each differential line,
100 Ω input impedance per differential pair
Synchronization
input signals Separate horizontal and vertical synchronizations,
polarity-free TTL level,
SOG (Composite SYNC on green)
AC input voltage/
frequency/current 100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 0.6 A
Inrush current 30 A (120 V AC Input)
60 A (240 V AC Input)
Model E2020H/E2220H
Video input signals • Analog RGB: 0.7 V ± 5 %,
75 Ω input impedance
• DP, 600 mV
for each differential line,
100 Ω input impedance per differential pair
Synchronization
input signals Separate horizontal and vertical synchronizations,
polarity-free TTL level,
SOG (Composite SYNC on green)
AC input voltage/
frequency/current 100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 0.7 A
Inrush current 30 A (120 V AC Input)
60 A (240 V AC Input)
