20 │ About your monitor
Physical characteristics
Model E1920H/E2020H/E2220H
Signal cable type:
Analog
Digital D-Sub (VGA), 15 pins
(cable is included for EMEA and JPN region only);
DP, 20 pin
NOTE: Dell monitors are designed to work optimally with the video cables that are
shipped with your monitor. As Dell does not have control over the different cable suppliers
in the market, the type of material, connector and process used to manufacture these
cables, Dell does not guarantee video performance on cables that are not shipped with
your Dell monitor.
Dimensions
(with stand):
E1920H E2020H E2220H
Height 359.60 mm (14.16 in.) 368.96 mm (Maximum)
(14.53 in.) (Maximum)
397.30 mm (15.64 in.)
Width 445.40 mm (17.54 in.) 471.52 mm (Maximum)
(18.56 in.) (Maximum)
512.20 mm (20.17 in.)
Depth 171.00 mm (6.73 in.) 171.00 mm (6.73 in.) 171.00 mm (6.73 in.)
Dimensions
(without stand): E1920H E2020H E2220H
Height 266.00 mm (10.47 in.) 275.36 mm (Maximum)
(10.84 in.) (Maximum)
303.70 mm (11.96 in.)
Width 445.40 mm (17.54 in.) 471.52 mm (Maximum)
(18.56 in.) (Maximum)
512.20 mm (20.17 in.)
Depth 50.10 mm (1.97 in.) 50.10mm (1.97 in.) 52.40 mm (2.06 in.)
Stand
dimensions: E1920H E2020H E2220H
Height 170.00 mm (6.69 in.) 170.00 mm (6.69 in.) 176.90 mm (6.96 in.)
Width 200.00 mm (7.87 in.) 200.00 mm (7.87 in.) 200.00 mm (7.87 in.)
Depth 171.00 mm (6.73 in.) 171.00 mm (6.73 in.) 171.00 mm (6.73 in.)
Weight E1920H E2020H E2220H
Weight with
packaging
3.92 kg (8.66 lb) 3.94 kg (8.68 lb) 4.90 kg (10.80 lb)
With stand
assembly and
cables
2.93 kg (6.46 lb) 2.94 kg (6.48 lb) 3.51 kg (7.74 lb)
Without stand
assembly and
cables
2.19 kg (4.83 lb) 2.20 kg (4.85 lb) 2.70 kg (5.95 lb)
Weight of stand
assembly
0.43 kg (0.95 lb) 0.43 kg (0.95 lb) 0.44 kg (0.97 lb)
