14 │ About your monitor
Monitor specifications
Model E2720H/E2720HS
Screen type Active matrix-TFT LCD
Panel type In-Plane Switching
Viewable area
Diagonal
685.99 mm (27 in.)
Active area
Horizontal
Vertical
Area
597.89 mm (23.54 in.)
336.31 mm (13.24 in.)
2010.76 cm² (311.67 in.²)
Pixel pitch 0.3114 mm x 0.3114 mm
Pixel per inch (PPI) 81
Viewing angle
Horizontal
Vertical
178° (typical)
178° (typical)
Brightness 300 cd/m² (typical)
Contrast ratio 1,000 to 1 (typical)
Faceplate coating Anti-glare with 3H hardness
Backlight LED light bar system
Response time
Normal mode
Fast mode
8 ms
5 ms
Color depth 16.7 million colors
Color gamut 72% (CIE1931)/83%(CIE1976)
Dell display manager
compatibility Yes
Connectivity E2720H: 1 x DP1.2, 1 x VGA
E2720HS: 1 x HDMI1.4, 1 x VGA
Bezel width (edge of
monitor to active area) 11.8 mm (Top)
11.8 mm (Left/Right)
18.2 mm (Bottom)
Security Security-lock slot for cable
lock (optional purchase)
Tilt angle -5° to 21°
Height adjustable stand E2720H: Non adjustable
E2720HS: 100+/-5 mma
Built-in Speakers
(2 x 1 W sound output) E2720H: No
E2720HS: Yes
