Dell E2020H 20" 16:9 TN Monitor - Manual (Page 13)

About your monitor │ 13
Monitor specifications
Model E2220H E2420H/E2420HS
Screen type Active matrix-TFT LCD Active matrix-TFT LCD
Panel type TN In-Plane Switching
Viewable area
Diagonal
546.86 mm (21.5 in.) 604.70 mm (23.8 in.)
Active area
Horizontal
Vertical
Area
476.64 mm (18.77 in.)
268.11 mm (10.56 in.)
1277.92 cm² (198.21 in.²) 527.04 mm (20.75 in.)
296.46 mm (11.67 in.)
1562.46 cm² (242.15in.²)
Pixel pitch 0.2482 mm x 0.2482 mm 0.2745 mm x 0.2745 mm
Pixel per inch (PPI) 102 92
Viewing angle
Horizontal
Vertical
170° (typical)
160° (typical) 178° (typical)
178° (typical)
Brightness 250 cd/m² (typical) 250 cd/m² (typical)
Contrast ratio 1,000 to 1 (typical) 1,000 to 1 (typical)
Faceplate coating Anti-glare with 3H hardness Anti-glare with 3H hardness
Backlight LED light bar system LED light bar system
Response time
Normal mode
Fast mode
5 ms
- 8 ms
5 ms
Color depth 16.7 million colors 16.7 million colors
Color gamut 72% (CIE1931)/83%(CIE1976) 72% (CIE1931)/83%(CIE1976)
Dell display manager
compatibility Yes Yes
Connectivity 1 x DP1.2, 1 x VGA E2420H: 1 x DP1.2, 1 x VGA
E2420HS: 1 x HDMI1.4, 1 x VGA
Bezel width (edge of
monitor to active area) 17.8 mm (Top)
17.8 mm (Left/Right)
17.8 mm (Bottom) 11.8 mm (Top)
11.8 mm (Left/Right)
18.2 mm (Bottom)
Security Security-lock slot for cable
lock (optional purchase) Security-lock slot for cable
lock (optional purchase)
Tilt angle -5° to 21° -5° to 21°
Height adjustable stand
-
E2420H: Non adjustable
E2420HS: 100+/-5 mm
Built-in Speakers
(2 x 1 W sound output)
-
E2420H: No
E2420HS: Yes
