Datavideo RMC-180 Mark II PTZ Camera Controller - Manual (Page 22)

22
4. Storing Different Camera Positions
The RMC-180 MARK II allows you to store up to four camera positions (PAN/TILT) for each of the
four possible cameras, CH A, B, C and D. This means, with four PTZ cameras connected to the RMC-
180 MARK II, up to sixteen camera positions can be stored.
Note: Positions and other settings stored in the camera cannot be accessed by the RMC-180 MARK
II.
To store a cameras position:
1. Select a camera first: CH A / CH B / CH C / CH D
2. Adjust the camera lens to the desired position or view using the joystick. Also set the focus, iris
and zoom of the selected camera.
3. Push the STORE button which should illuminate red.
4. As soon as the corresponding four preset buttons of the selected camera channel start blinking,
simply press a preset button to save the current PAN/TILT settings.
5. The selected preset button will remain ON for 2-3 seconds and the button LED will be turned
OFF after the settings are successfully saved.
