Pluto Trigger - Manual (Page 7)

1. Program status led
2. Microphone
3. Battery charging led
4. Shutter-release/Bluetooth
button
1. Laser/Light sensor
2. Infrared sensor
3. Infrared emitter
1. Power switch
2.5.1 S
HUTTER
R
ELEASE
B
UTTON
The shutter release button let you trigger your camera manually.
It is also used as a switch to turn on/off the Bluetooth module. To do this, just
press the button and hold for
5 seconds and the Status Led will show
notification. Three short blinks means Bluetooth is turned ON, while one
long blink means Bluetooth is turned OFF.
Turn off Bluetooth makes the battery life of Pluto Trigger much longer. It is
useful when you are taking long time-lapse sequence. You start the
program and then turn off Bluetooth. Pluto trigger runs at about half power
consumption. When you need to change settings, turn Bluetooth back on.
2.5.2 LED
The Status Led can be set to five modes as follows:
1 2 3
4
1 2 3
1
