Trailer tow hitch, Mounting dimensions, Technical data – Mercedes-Benz 2013 M Class User Manual
Page 456
ML 550 4MATIC
BlueEFFICIENCY
Vehicle length
190.5 in
(4839 mm)
ML 63 AMG
Vehicle length
189.6 in
(4817 mm)
Vehicle width including
exterior mirrors
84.3 in
(2141 mm)
Maximum vehicle height
71.3 in
(1812 mm)
Minimum vehicle height
69.0 in
(1752 mm)
Wheelbase
114.8 in
(2915 mm)
Maximum ground
clearance
9.1 in
(231 mm)
Minimum ground
clearance
6.7 in
(171 mm)
Turning radius
38.7 ft
(11.80 m)
Maximum roof load
220 lb
(100 kg)
Trailer tow hitch
Mounting dimensions
!
If you have a trailer tow hitch retrofitted,
changes to the cooling system and drive
train may be necessary, depending on the
vehicle type.
If you have a trailer tow hitch retrofitted,
observe the anchorage points on the
chassis frame.
Anchorage points for the trailer tow hitch
(example)
:
Anchorage points
;
Rear axle center line
454
Trailer tow hitch
Technical data
