SELECTING/EDITING/SAVING PATTERNS ————————————————————————————————————————
128
Changing the colors of the
pattern
The colors of the pattern can be changed and
previewed on the screen.
By changing the colors of the pattern, the same
pattern can be viewed in various ways.
If your thread colors are registered in a color thread
table and if you used the table for changing color,
the thread spools can be assigned with the thread
colors that you have. And the pattern displayed in
the screen will appear with colors that are almost the
same as the actual thread colors
With this operation, the colors of all patterns will be
changed, not just those of the pattern being edited.
1
Touch .
X
The change thread color screen appears.
1 The part of the pattern in the color at the top of
the thread color sequence display is the part
whose color is being changed.
2 Shows the number of thread color changes. The
top value shows the position in the sewing order
for the color at the top of the thread color
sequence display and the bottom value shows the
total number of thread color changes.
3 Selects the previous color in the thread color
sequence display
4 Selects the next color in the thread color
sequence display
5 Use these keys to select a color from the color
thread table.
6 Applies the color change
7 Color thread table
Select a color from this table.
8 Specifies pause locations (Refer to “Specifying
pause locations before embroidering” on
page 92.)
9 Touch this key to close this screen.
0 Name of the table
2
Touch
and
until the color to be
changed appears at the top of the thread color
sequence display.
1 The thread color for the part of the pattern
displayed at the top will be changed.
3
Touch , ,
and
to select the
new color from the color palette.
1 The color that appears enlarged is the color that is
selected.
2 Displays the name of the selected thread color
X
In the pattern display area, the color of the
selected part of the pattern is changed.
