5-2
BE1-50/51M Testing
9252000990 Rev R
Figure 5-1. Pickup and Timing Test Setup
Figure 5-2. Target Operational Test Setup
BE1-50/51M
9
8
7
6
5
4
2
TIME
INST
3
CURRENT
SOURCE
INPUT
STOP
TIMER
START
AMPS
TEST SET
D2750-21
R
AC or DC
Voltage
Source
(V)
1 A Target Current
R = V/1
Rwatts = 1*V
