Figure 4-13. Panel Cutting/Drilling, Semi-Flush, M1 Case
3.03 (77)
6.06 (154)
0.25 (6) diameter, 4 places
CL
Cut-Out
0.575
(15)
14.63
(371.5)
0.552
(14)
5.69 (144.5)
Outer Edge of Cover
0.480
(12)
14.25
(362.1)
7.13
(181.0)
0.480
(12)
P0072-21
7.31
(185.7)
2.84 (72.1)
4-14 BE1-32R, BE1-32O/U Installation 9171100990 Rev T
