E-8000 41 9.17.076
4.3.5 Electrical properties
Art. Nr. Module Rear Type
Label Information
Power Supply Power max. Fuse mains/primary
Fuse
secondary
Tmax
4.08.242 E-8005-x-xWxxU/3 110…120V 200VA 50-60Hz T2A I2t >30A
Littelfuse 0213002.MXP
or equivalent T4A 40°C
4.08.243 E-8003-x-xWxxU/3 220…240V 200VA 50-60Hz T1A I2t >10A
Littelfuse 0213001.MXP
or equivalent T4A 40°C
4.08.245 E-8003-x-xWxxV/3 220…240V 1650VA 50-
60Hz T10A - 40°C
4.08.248 E-8005-x-xWxxU/0 110…120V 200VA 50-60Hz T2A I2t >30A
Littelfuse 0213002.MXP
or equivalent T4A 40°C
4.08.249 E-8003-x-xWxxU/0 220…240V 200VA 50-60Hz T1A I2t >10A
Littelfuse 0213001.MXP
or equivalent T4A 40°C
4.08.251 E-8003-x-xWxxV/0 220…240V 1650VA 50-
60Hz T10A - 40°C
4.3.6 Instrument I/O connection
Connection to remote equipment, I/O.
The male I/O (sub-miniature 9-pin) D-connector has the following pin configuration:
Pinnumber description
1 RS485(B)
2 analog output
3 analog input
4 0V power
5 + actuator out / special
6 RS485(A)
7 not connected
8 0V sense
9 shield
Analog input/output signals
Analog input signals should be connected to pin 3 (+) and 0V power.
Analog output signals are available at pin 2 (+) and 0V power.
Signals are according to one of the Bronkhorst HIGH-TECH B.V. standards. The model configuration contains a code, describing the
input/output signals.
Note:
a. Max. load current output (sourcing)
: 375 Ohm
b. Min. load voltage output : 10 kOhm
c. Input load resistance (voltage) : 22K4
d. Input load resistance (current) (sinking) : 200 Ohm
