1 Scope of this manual
1.1 Introduction
The Bronkhorst High-Tech B.V. series E-8000 is a modular Power Supply/Readout and Control (R/C) system for digital mass flow /
pressure meters and controllers. Every model can be fitted with or without displays.
Note: Because the E-8000 uses the RS232 port of these instruments for communication, other RS232 communication
is not possible. When the instrument is connected with a bus-system like PROFIBUS DP or DeviceNet™,
communication with this bus-system will not be effected. Measure, setpoint and other parameters can be “read-and-
write” by the
E-8000 or via the bus-system.
1.2 References to other applicable documents
Hookup diagrams
E-8000 Readout - Supply (doc. nr. 9.16.112)
E-8000 Readout - RS232 + Supply (doc. nr. 9.16.113)
E-8000 Readout - FLOW-BUS + Supply (doc. nr. 9.16.114)
E-8000 CEM Controller - Analog I/O (doc. nr. 9.16.102)
E-8000 CEM Controller - RS232 (doc. nr. 9.16.103)
E-8000 CEM Controller - FLOW-BUS (doc. nr. 9.16.104)
E-8000 CEM Controller - PROFIBUS DP (doc. nr. 9.16.105)
E-8000 CEM Controller - DeviceNet™ (doc. nr. 9.16.106)
E-8000 CEM Controller - Modbus (doc. nr. 9.16.107)
E-8000 CEM Controller - EtherCAT® (doc. nr. 9.16.108)
E-8000 CEM W-10xA/202A (doc. nr. 9.16.109)
E-8000 CEM W-303B 230Vac (doc. nr. 9.16.115)
E-8000 CEM W-303B 120Vac (doc. nr. 9.16.116)
i
www
These documents can be downloaded from the website: www.bronkhorst.com or can be sent by e-mail on request.
Dimensions
Refer to section 2.4.4 'Housing dimensions'.
1.3 Technical data display
1.8” colour TFT display with a 128x160 pixel resolution
100 MHz Processor
15..24Vdc 0.6W Power Consumption
RS232 38k4 communication
Operating temperature 0..40°C
