5.7

TECHNICAL DATA

SCM5

To remove the coffee machine from its housing,
it is first of all necessary to disconnect it from
the mains electricity by unplugging it.
Then press the relevant joints (B) in the guides
and remove the appliance, being sure to sup-
port it on the bottom.

5.5

DISASSEMBLY

the guides again.

• When fitting into the unit, the appliance will

automatically hook onto the points (A) on
the guides.

COFFEE MACHINE

CLASSE I

RATED VOLTAGE

220/230V

ELECTRICAL
INPUT

1500W

CONNECTION

1.8KW (predisposto
per essere collegato)

POWER CORD

1.2m / 47,24 inc

APPLIANCE
DIMENSIONS
(L X D X H)

594X440X464mm
23,39X17,32X18,27inc

COMPARTMENT
DIMENSIONS
(L X D X H)

560X550X450mm
22,05X21,65X17,72inc

NET WEIGHT

52Kg / 114Lb.

GROSS WEIGHT

63KG / 139Lb.

AMOUNT OF
WATER

5 Lt / 1,321gal.

Open the lid in the top part; then remove and fill
the water tank and close the lid.

Powdered
or decaf-
f e i n a t e d
coffee

WARNING

Only pour coffee beans into the container.
Any other type of coffee - ready ground for
example – will damage the grinder.

The machine is equipped with 2 light gems with
the following technical data:

- LIGHT GEM CLASS 1
-

MAXIMUM POWER OF THE LIGHT GEM
RADIATION: 4.0MW

THE WAVELENGHT IS 470MM

CLASSIFICATION AND PUBLICATION
DATE: IE60825-1 EDITION: 1993 CONSO-
LIDATED BY THE AMENDMENTS 1:1997
AND 2:2001

Please, avoid the exposure of the eyes in
the direction of the light gems.

5.6

LIGHTING
