- 15 -
Power
Input Voltage
12/24/48 VDC (9.6 to 60 VDC),
18 to 30VAC (47 to 63 Hz)
Input Current @ 24VDC 0.1 A (EDS-205A)
0.11 A (EDS-205A-M/S)
0.13 A (EDS-208A)
0.17 A (EDS-208A-M/S)
0.22 A (EDS-208A-MM/SS)
Connection Removable 4-contact terminal block
Overload Current
Protection 1.1 A
Reverse Polarity Protection Present
Physical Characteristics
Housing
IP30 protection, metal case
Dimensions EDS-208A Series: 50 x 115 x 70 mm
EDS-205A: 30 x 115 x 70 mm
Weight EDS-208A Series: 275 g
EDS-205A: 175 g
Installation DIN-Rail Mounting, Wall Mounting
(with optional kit)
Environmental Limits
Operating Temperature
-10 to 60°C (14 to 140°F)
-40 to 75°C (-40 to 167°F) for -T models
Storage Temperature -40 to 85°C (-40 to 185°G)
Ambient Relative Humidity 5 to 95% (non-condensing)
Regulatory Approvals
Safety
UL508 (pending)
Hazardous Location UL/cUL Class I, Division 2, Groups A, B, C, and
D; ATEX Class I, Zone 2, Ex nC nL IIC T4
(Pending)
EMI FCC Part 15, CISPR (EN55022) class A
EMS EN61000-4-2 (ESD), Level 3
EN61000-4-3 (RS), Level 3
EN61000-4-4 (EFT), Level 3
EN61000-4-5 (Surge), Level 3
EN61000-4-6 (CS), Level 3
EN61000-4-8
EN61000-4-11
Shock IEC 60068-2-27
Freefall IEC 60068-2-32
Vibration IEC 60068-2-6
WARRANTY 5 years
- 16 -
Technical Support Contact Information
www.moxa.com/support
Moxa Americas:
Toll-free: 1-888-669-2872
Tel: +1-714-528-6777
Fax: +1-714-528-6778 Moxa Europe:
Tel:
+49-89-3 70 03 99-0
Fax: +49-89-3 70 03 99-99
Moxa Asia-Pacific:
Tel: +886-2-8919-1230
Fax: +886-2-8919-1231 Moxa China (Beijing office):
Tel: +86-10-6872-3959/60/61
Fax: +86-10-6872-3958
