Chapter 3 Hardware Installation
22
Chapter 3
Standby Power LED
Standby
Power LED
This LED will light when the system is in the standby mode.
Cooling Option
Heat Sink with Cooling Fan
• “1” denotes the location of the thermal pad designed to contact the corresponding
components that are on HU968.
Top View of the Heat Sink
Important:
Remove the plastic covering from the thermal pads prior to mounting the heat sink
onto HU968.
Note:
The system board used in the following illustrations may not resemble the actual
board. These illustrations are for reference only.
Bottom View of the Heat Sink
1
