Chapter 4 – DFI HU968 User Manual
Page 31
www.dfi .com
Chapter 4 BIOS Setup
31
Chapter 4
ACPI Settings
This section is used to configure ACPI settings.
ACPI Sleep State
Select the ACPI sleep state that the system will enter when the Suspend button is
pressed.
S3(STR) Enable the Suspend to RAM function.
Resume by PME
Enable this field to use the PME signal to wake up the system (via PCI, PCIE and
onboard LAN).
Resume by RTC Alarm
When Enabled, the system uses the RTC alarm to generate a wakeup event.
Select ACPI sleep state
the system will enter when
the SUSPEND button is
pressed.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
ACPI Settings
ACPI Sleep State
Resume by PME
Resume by RTC Alarm
Advanced
[S3 only (Suspend to...)]
[Enabled]
[Disabled]
Select Screen
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save & Reset
ESC: Exit
Trusted Computing
This section configures settings relevant to Trusted Computing innovations.
Enables or Disables
BIOS support for security
device. O.S. will not show
Security Device. TCG
EFI protocol and INT1A
interface will not be
available.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Confi guration
Security Device Support
Current Status Information
SUPPORT TURNED OFF
Advanced
Security Device Support
Enables or Disables the BIOS support for the security device. O.S. will not show the
security device. TCG EFI protocol and TNT1A interface will not be available.
[Disable]
Select Screen
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save Changes and
Reset
ESC: Exit
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Version 2.15.1236. Copyright (C) 2012 American Megatrends, Inc.
Confi guration
Security Device Support
TPM State
Pending operation
Current Status Information
TPM Enabled Status:
TPM Active Status:
TPM Owner Status:
Advanced
[Enabled]
[Enabled]
[None]
[Enabled]
[Activated]
[Unowned]
Select Screen
Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous
Values
F3: Optimized
Defaults
F4: Save Changes and
Reset
ESC: Exit
Enables or Disables
BIOS support for security
device. O.S. will not show
Security Device. TCG
EFI protocol and INT1A
interface will not be
available.
