Chapter 3 Hardware Installation

28

Chapter 3

Side View of the Module, Debug Card and Carrier Board

7. Use the long mounting screws to secure the heat sink on the top of the HU968 and the

COMe-LINK1 debug card and connect the cooling fan’s cable to the fan connector on

HU968. The photo below shows the locations of long mounting screws.

Long screws

COMe-LINK1

Carrier Board

HU968

COMe-DEBUG

Cable
