StockWeigh 550 EID and StockWeigh Link
26
ANIMAL This CSV format includes information for animal weighing.
Includes $' if unit is "locked on",weight, weight tag (GR, M+, etc...), display
unit, Memory Weight (RM), Average Count (Number of times M+ key was
pressed), Average Weight, Gross weight on scale, ID, date and time.
Ends with a <CR>,<LF>.
Print example:
" , 1400,GR,LB, 2180, 4, 545, 1400, ,11:09,13MR02"
3200 A See service bulletin # 19 for details.
3200 B See service bulletin # 20 for details.
32 TMR See service bulletin # 19 for details.
BATCH1 Contact Digi-Star technical support for details.
FDINFO Contact Digi-Star technical support for details.
WTRCTM
This CSV format includes basic weighing information.
Includes Gross Weight, display unit, weight tag (GR, M+, etc...), Total
Rotation Count, Date & Time.
Ends with a <CR>,<LF>.
Print example:
" 280,LB,GR, 187,03JL03, 3:41P"
EIDINF This CSV format includes EID memory status information.
Ends with a <CR>,<LF>.
The response from the StockWeigh 550 EID Indicator will be as follows:
“
uuuuuu,UUUUUU,mmmmmm<CR><LF>”
uuuuuu = Used Livestock EID lines (6 digits)
UUUUUU = Un-used Livestock EID lines (6 digits)
mmmmmm = Maximum Livestock EID lines (6 digits)
<CR> 'Carriage Return' [0D] hex or [13] decimal
<LF> 'Line Feed' [0A] hex or [10] decimal
Print example:
" 157, 1379, 1536"
EID This CSV format includes EID tag number if available, weight info, date, and
time.
Print example:
,
860,LB,$,GR,03/09/04,08:58,j
Print example (1L PRT=ON):
, 860,LB,$,GR,03/09/04,08:58,j
NOTE: Only the StockWeigh 550 EID indicator supports EID memory storage.
