StockWeigh 550 EID and StockWeigh Link
28
Appendix G
Weighing Errors
OVRCAP
Capacity Limit:
The display shows the message "
OVRCAP
" if the weight on the scale system exceeds the capacity
limit. The capacity value is entered in SETUP to warn of overloading the scale system.
+RANGE
Over Range:
The display shows the message "
+RANGE
" if the weight on the scale system exceeds the maximum
weight measurable by the scale system. The over range value is always the system’s maximum
A/D counts multiplied by the scaling factor. The actual weight at which over range occurs depends
on the calibration, zero, and display count size.
-RANGE
Under Range:
The display shows the message "-
RANGE
" if the weight on the scale system is less than the
minimum weight measurable by the scale system. The under range value is always the system’s
minimum A/D counts multiplied by the scaling factor. The actual weight at which under-range occurs
will depend on the calibration, zero, and display count size.
NOTE:
The EZII Series supports –RANGE that is equal to +RANGE in absolute value.
