Operators Manual
D3645 1
StockWeigh 550 EID
The Digi-Star StockWeigh 550 EID indicator is designed to weigh livestock, collect EID (electronic
identification) and store the information (tag number, weight, date and time) in the indicator memory
for later transfer to a PC. The Lock-On feature allows this scale to weigh active and restless
animals within ±1% of actual weight. This indicator can be connected to various load cell systems.
StockWeigh Link
 PC Software easily transfers the data that has been collected to a comma
separated value (CSV) file on a PC.
What You Get
StockWeigh 550 EID  Indicator
Power Cable with Battery Clips (for 12 Volt DC Operation)
Power Cube (for 120 Volt AC Operation)
Serial Interface Cable (For Connecting to a PC)
StockWeigh Link
 PC Software CD
Optional Equipment
Allflex
 ISO Compatible RFID Stick Reader (order separately)
StockWeigh 550 EID Specifications
The indicator interfaces with Allflex  ISO Compatible RFID Readers.
The Indicator can hold information for up to 1536 animals in its memory.
The indicator can connect up to an ordinary PC via the serial port and transfer the livestock data to
a PC.
Each line of data has seven data fields including:
1.
EID Data
2. Weight Value
3. Unit of Measure (LB/KG)
4. “$” Indicating Weight Locked-On
5. “GR” for Gross or “NT” for Net Mode
6. Date
7. Time
