Grass Valley GV STRATUS Playout v.2.0 - Manual (Page 89)

89
GV STRATUS Playout
Operator Manual
• All Channels: to select a channel from a list of all the channels in the selected view.
To filter the column, click Contains in the column you want to search and type the
text or character that you want to use in the search.
• Channel Hierarchy: to select a channel from list of all the channels in the selected
view organized by their channel hierarchies.
4 Click Empty Channel.
5 In the Empty Channel dialog box, click Yes.
Editing the playlist on a specific channel
You can make live edits to the playlist currently in progress on the Channel Control page by
clicking the Edit Playlist button. When you click Edit Playlist, it opens the Schedule Edit
page in a special mode that allows you to edit the playlist playing on the channel. Changes
that you make while in this special mode are specific to the channel and do not get saved to
the schedule itself, and therefore do not affect other channels playing the same schedule.
However, if the channel you are editing is a parent channel, the changes are propagated
down to its child channels. Changes made on a child channel do not affect the parent
channel.
When the Schedule Edit page is in the special mode, the name of the schedule that is
normally displayed at the top of the channel grid is replaced by the name of the channel
that you editing and the channel grid is highlighted to draw your attention to it being in a
different mode.
To edit the playlist:
1 In the top menu, click Channel Control.
2 In the Select View list, click the view that you want displayed in the left pane.
3 Click one of the following:
• All Channels: to select a channel from a list of all the channels in the selected view.
To filter the column, click Contains in the column you want to search and type the
text or character that you want to use in the search.
• Channel Hierarchy: to select a channel from list of all the channels in the selected
view organized by their channel hierarchies.
4 Click Edit Playlist. The Schedule Edit page opens in the special mode.
5 Make the changes to the playlist as required.
Showing and hiding secondary events
The Secondaries button allows you to show or hide the secondary events from the channel
grid. When the Secondaries button is blue, it is enabled and the secondary events are
displayed in the channel grid. When the button is grey, the secondary events continue to
appear in the playout, but they are not visible in the channel grid.
To show or hide the secondary events in the channel grid:
1 In the top menu, click Channel Control.
Note: A clip may take up to 15 seconds to cue depending on the file size,
structure (indexing), and bit rate.
