Mouse/Keyboard EMI Board
PDR 200 Service Manual
6-39
To install the Mouse/Keyboard EMI board:
1. Position the board in the Profile chassis so that the connectors protrude out of the rear
panel.
2. Align the screw holes and use the Torx tool with the T10 tip to secure the board to the
Profile chassis with the screws previously removed (Figure 6-25).
3. Connect the cable previously removed to the board.
4. Reinstall any boards removed (Figures 6-20 and 6-21 and pages 6-33 and 6-34).
5. Replace chassis covers (page 6-8) and reinstall the chassis in the rack (page 6-7).
6. Reconnect the power cord and turn PDR200 power On.
