Chapter 6 Parts Removal and Replacement
6-48
PDR 200 Service Manual
PAC208/216 Replaceable Parts
Table 6-3 lists the replaceable parts for the PAC208/216. The removal and
replacement procedures do not cover all the parts listed in Table 6-3.
.
PAC208/216 Bezel and Air Filter
Under all but the most exceptional circumstances the front panel bezel should rarely
require replacement. See ‘Cleaning or Replacing Air Filters’ in Chapter 5 for the
procedure to remove and replace the air filter.
Table 6-3. PAC Replaceable Parts List
Description
Part Number
PAC208 Replacement Unit
118-9538-XX
PAC216 Replacement Unit
118-9539-XX
Expansion Chassis, Digital
437-0455-XX
PAC Digital Transition Board
671-3895-XX
PAC Expansion Transition Board
671-3885-XX
PAC XLR Board
671-3683-XX
Cable, Champ to Champ
174-3678-XX
Cable, LED Assy
174-3617-XX
Fan
119-4827-XX
Power Supply
119-5437-XX
Switch Cable Assy
174-3613-XX
PAC Front Panel Bezel
333-4201-XX
Air Filter, PAC208
378-0436-XX
Cable, AC w/Switch
174-3612-XX
PAC Main Board
671-3649-XX
PAC Daughter Board
671-3861-XX
Cable, Pwr Supply to Main Board
174-3614-XX
