Diagnostic Test Exceptions
PDR200 Service Manual
4-31
VGA Board (Slot J2)
The VGA board resides in a non-EISA slot and, therefore, cannot be recognized by
the diagnostics. Selecting this board brings up the message shown in Figure 4-11.
Figure 4-11. VGA Slot Message
Ethernet LAN Board (Slot J3)
The LAN board currently does not have diagnostic testing. Selecting the board brings
up the message shown in Figure 4-12.
Figure 4-12. LAN and SCSI Boards Message
SCSI Board (Slot J4)
The SCSI board currently does not have diagnostic testing. Selecting the board brings
up the same message shown in Figure 4-12.
