45
OPERATION
Power Take-Off (PTO) (Model HD
PTO
)
The front PTO is standard equipment on the HD PTO model only.
The PTO must be in the disengaged (OFF) position before the engine can be started.
The PTO has a rated speed of 2000 RPM.
WARNING!
• Do Not exceed the rated attachment PTO speed.
• Stay clear of rotating driveline
• Keep bystanders away.
• Keep hands, feet, clothing and long hair away.
• Keep PTO shields and guards in place.
• Disengage PTO, put gear selector in PARK, stop the
engine and make sure all rotating components are
stopped before exiting utility vehicle.
• Do Not service the utility vehicle or attachment with the
PTO engaged.
• Do Not service the attachment in a raised position unless
properly blocked and all rotating components stopped.
• Disengage PTO for road travel.
Engaging PTO
Tip: Do not engage the PTO system at higher engine RPM
with the attachment under load. Always engage the PTO system at a lower engine RPM and with
the attachment under a no load condition.
1. The operator must be in the operator seat to engage
the PTO system. If the operator exits the machine
with the PTO engaged, the PTO will shut off.
2. Reduce the engine speed.
3. Press the center button of the PTO switch and then
pull up on the knob to engage the PTO.
4. The light in the dash will illuminate and the PTO
shaft will start rotating. The PTO RPM will be
displayed.
5. Increase the engine speed to the desired RPM
specified for your attachment. See your attachment Owner’s Manual for the correct PTO
RPM.
Disengaging PTO
1. Reduce the engine speed to low idle.
2. Press down on the PTO switch to the disengaged (OFF) position. The light in the dash
will turn OFF and the PTO shaft will stop rotating.
WARNING! Avoid Injury Or Death
• Keep PTO shield and all guards in place.
• Keep away from moving parts.
• Keep bystanders away.
• Do NOT exceed 2000 PTO RPM.
PTO Switch
PTO
Light
PTO
RPM
