SLIM-BASIC COMFORT AIR KIT
Chapter 3
USE AND MAINTENANCE MANUAL
page
18
Basic comfort air kit
Technical dept. - All rights reserved by MCZ Group S.p.A. - Reproduction prohibited
2.2.3.1.
Glass insertion diagram
FLIP-FLOAT glass insertion
Position the glass by inserting the supporting hooks into the purpose-
provided slits, sliding it down. The upper hooks will be inserted into the
support holes while the lower ones only at the top.
SUPPORT
HOLES
HOOKS
FLIP
FLOAT
HOOKS
