SLIM-BASIC COMFORT AIR KIT
Chapter 3
USE AND MAINTENANCE MANUAL
page
28
Basic comfort air kit
Technical dept. - All rights reserved by MCZ Group S.p.A. - Reproduction prohibited
2.5.3.
Modifying the transmission/reception
channel
If there are two control units within a range of 100-200m, the
transmission/reception channel needs to be changed. Here's how.
1. To change channel on the TLC, proceed as follows:
Channel 0 (by default): press the 2 keys at the top concurrently
Channel 1: press the 2 keys on the right concurrently
Channel 2: press the 2 keys at the bottom concurrently
Channel 3: press the 2 keys on the left concurrently
During this operation, the yellow LED flashes, release the keys only
after it is turned off.
2. To set the corresponding channel on the control unit:
- Short-circuit the sensor input (make a jumper).
- Power the board
- On the remote control, press the key for the required channel for
a few seconds:
P1(+ light) = channel 0
P2(+ fan) = channel 1
P3(-light) = channel 2
P4(-fan) = channel 3.
3. remove the jumper from the sensor input.
2.5.4.
Replacing the remote control battery
The battery is seated at the rear of the remote control. To replace it,
use a sharp item (such as a screwdriver) to prise open the cover. Once
the cover has been removed, replace the battery, observing the right
polarity (+) and (-). Close the cover of the battery compartment.
An alkaline 23A 12 Volt battery is necessary for operation.
Used batteries contain metals that are harmful to the
environment. Therefore, they must be disposed of
separately in suitable containers.
BATTERY
COMPARTMENT
COVER
