Subaru Robin RGV12100 - Manual (Page 19)

16
SINGLE-PHASE OUTPUT
W G
Y
X
Z
Three phase application (208V)
Insert the plug into the receptacle X, Y and
Z.
Generator rated output : 10000VA
AC (THREE PHASE) RECEPTACLE
(RGV13100T only)
RGV13100T has a receptacle for three plase
(208V) and single phase (120V) as follows :
Single phase lower application (120V)
Insert the plug into the receptacle W and X,
W and Y, W and Z.
Maximum one-third (1/3) of generator output
can be utilized from each phase.
W G
Y
X
Z
3-PHASE OUTPUT
Generator rated output :
3324VA (120V x 27.7A)
SINGLE PHASE AC120V
THREE PHASE AC208V
W
Y
X
Z
