26
ROTOR
Measure the resistance between the slip ring
and the core.
CONTROL PANEL
Measure the insulation resistance between
the live parts and the grounded parts.
CURRENT TRANSFORMER (RGV13100T)
Measure the insulation resistance between
each terminal and the core.
If it is less than 1M
, replace the current
transformer.
Any part where the insulation resistance is
less than 1M
has faulty insulation, and may
cause electric leakage and electric shock.
Replace the faulty part.
