NETGEAR M4350-24F4V 24-Port 10G SFP+ Managed AV Network Switch User Manual
Page 893
usage of text-based configuration is to upload a working configuration from a
device, edit it offline to personalize it for another similar device (for example,
change the device name or IP address), and download it to that device. This is
the default setting.
•
DHCP Client Configuration File: The DHCP client configuration file with the
DHCP server (host) information.
7. If the selection from the File Type menu is Software, the Image Name menu displays
and you must select the software image that must be downloaded to the switch:
•
Image1: Select image1 to upload image1.
•
Image2: Select image2 to upload image2.
We recommended that you do not overwrite the active image.
8. In the File Path field, specify the path on the USB storage device.
You can use up to 146 characters. The default is blank.
9. In the USB File field, specify the file name on the USB storage device.
You can enter up to 32 characters.
10. Click the Apply button.
The file is downloaded from the USB storage device to the switch. The page displays
information about the progress of the file transfer.
11. To save the settings to the running configuration, click the Save icon.
Download and install an SSL security
certificate file on the switch
If you use HTTPS instead of HTTP to access the main UI, you are not required to obtain
an SSL certificate. The security warning that might display in your browser prompts you
to confirm that the self-signed certificate of the switch is valid. Once you do so, the
browser warning might no longer display when you log in.
However, if you obtain an SSL security certificate from a certificate authority, you can
download and install the SSL security certificate through an HTTP session using your
web browser.
For an SSL security certificate, you must download two Privacy Enhanced Mail (PEM)
files to the switch:
•
SSL Trusted Root Certificate PEM File: The SSL trusted root certificate PEM file,
which must be in the format
xxxxCERTxxxxx.pem
.
•
SSL Server Certificate PEM File: The SSL server certificate PEM file (the key file),
which must be in the format
xxxxKEYxxxxx.pem
.
Main User Manual
893
Maintenance and
Troubleshooting
Fully Managed Switches M4350 Series Main User Manual
