Functional Description
SCP-P4040-4G-ENP2 Installation and Use (6806800P60B)
42
GPIO18, 19, 20, 23, 24 and 26 are multiplexed with other functional blocks. The pins should be
configured as GPIO in RCW data.
GPIO18/19: RCW [DMA1]=1b
GPIO20: RCW [DMA2]=10b
GPIO23/24/26: RCW [IRQ]=1b
CPU_GPIO23
Clock generator of bank 1 frequency
selection
CPU_GPIO24
Clock generator of bank 2 frequency
selection
CPU_GPIO26
Clock generator of bank 3 frequency
selection
IOEXT_GPI5
GPI5 of COME connectors
IOEXT_GPI6
GPI6 of COME connectors
IOEXT_GPI7
GPI7 of COME connectors
IOEXT_GPI8
GPI8 of COME connectors
IOEXT_GPO5
GPO5 of COME connectors
IOEXT_GPO6
GPO6 of COME connectors
IOEXT_GPO7
GPO7 of COME connectors
IOEXT_GPO8
GPO8 of COME connectors
Table 4-6 GPIO (continued)
GPIO Name
Function
