BIOS Setup
IDE Auto-Detection
Detects the parameters of the drive. The parameters will automati-
cally be shown on the screen.
Extended IDE Drive
If you select ”Auto”, the BIOS will auto-detect the HDD & CD-
ROM drive at the POST stage and show the IDE for the HDD &
CD-ROM drive. If a hard disk has not been installed, select “None”.
Access Mode
For hard drives larger than 528MB, you would typically select the
LBA type. Certain operating systems require that you select CHS or
Large. Please check your operating system’s manual or Help desk on
which one to select.
The settings on the screen are for reference only. Your version may not be
identical to this one.
IDE Channel 0 Master to IDE Channel 3 Master
To configure the IDE drives, move the cursor to a field then press
<Enter>. The following screen will appear.
IDE Auto-Detection
Extended IDE Drive
Access Mode
Capacity
Cylinder
Head
Precomp
Landing Zone
Sector
Phoenix - AwardBIOS CMOS Setup Utility
IDE Channel 2 Master
Item Help
Menu Level XX
To auto-detect the
HDD’s size, head... on
this channel
↑↓→← : Move Enter: Select F1: General Help +/-/PU/PD: Value F10: Save ESC: Exit
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
38309
16
0
38308
255
Press Enter
Auto
Auto
80 GB
