26 DR ® TRIMMER/MOWER
Be certain to fill with oil before starting the engine. See page 10.
8. Install the Axle Nut and tighten it firmly with a 5/8" Wrench. The installation is now complete.
NOTE: You have properly installed the Wheel when the Wheel locks against the Axle when you pull the Trimmer backward, and will
freewheel when pushed forward. The design of the Wheel Bearings is to be directional.
9. Repeat steps 2 through 8 for the opposite Wheel.
Engine Oil - All models
Tools and Supplies needed:
 SAE 30 HD Oil (refer to your Engine Owner’s Manual for quantity required)

Suitable container for used oil

Rags

Wooden pallet or workbench
NOTE: Drain the oil when the Engine is warm. Warm oil drains quickly and
completely.
1. For convenience, place the machine up on a wooden pallet or workbench.
2. Remove the Oil Filler Cap and position a suitable oil receptacle beside the
Oil Fill Tube.
3. Make sure to securely tighten the Gas Fill Cap.
4. Using the handle of the DR TRIMMER/MOWER, tip the machine to the left
and drain the oil out through the Oil Filler Tube (Figure 43) into a suitable
receptacle.
5. Refill the Engine using SAE 30 HD oil to the level indicated on the Dipstick.
See page 10.
6. Reattach the Spark Plug wire.
NOTE: Be sure to use environmentally safe disposal procedures in the disposing of
the used oil.
Before performing any maintenance procedure or inspection, stop the engine, wait five (5) minutes to allow all parts to cool.
Disconnect the spark plug wire, keeping it away from the spark plug.
Tightened Fuel
Fill Cap
Figure 43
Oil Fill Tube
