38 DR ® TRIMMER/MOWER
Parts List - Main Frame Assembly - All Models
NOTE: Part numbers listed are available through DR Power Equipment.
Ref# Part# Description
1 292001 Frame, Main, W/ Labels, TR3, non-Self-
Propelled
292011 Frame, Main, W/ Labels, TR3 Self-
Propelled
2 111581 Bolt, HCS, 5/16-18 X 1"
3 143781 Guard, Debris
4 114431 Belt, 1/2 X 45, 4L 450
5 119191 Pulley, V-Belt, 4.00"
6 143511 Arm, Brake
7 143521 Rod, Brake Connecting
8 110761 Nut, Nylon Lock, 5/16-18
9 112381 Washer, Flat, 1/4", USS
10 152501 Bolt, HCS, 1/4-20 x 3/4", Flanged, ZP
11 110731 Nut, Nylon Lock, 1/4-20
12 225811 Shield, Outer Lower, W/ Labels
13 110701 Nut, Finish, 1/4-20, ZP
14 143751 Washer, .505" ID X 1.0" OD
15 143581 Arm, Clutch
16 143601 Standoff, Clutch Arm
17 143831 Bracket, Clutch, Deck
18 118731 Nut, Nylon Lock, 10-24
19 151401 Screw, 1/4-20 X .750", Tri-Lobe
20 143811 Shield, Inner Lower
21 292051 Engine, B&S, 6.25 Ft/Lbs, MS, 50st, Ca,
W/ Labels
292061 Engine, B&S, 6.25 Ft/Lbs, ES, 49st, W/
Labels
292071 Engine, B&S, 6.25 Ft/Lbs, ES, 50st, Ca,
W/ Labels
292081 Engine, B&S, 6.75 Ft/Lbs, MS, 50st, Ca,
W/ Labels
292091 Engine, B&S, 6.75 Ft/Lbs, ES, 49st, W/
Labels
292101 Engine, B&S, 6.75 Ft/Lbs, ES, 50st, Ca,
W/ Labels
292111 Engine, B&S, 6.75 Ft/Lbs, MS, 49st, W/
Labels
292411 Engine, B&S, 6.25 Ft/Lbs, MS, 49st, W/
Labels
Ref# Part# Description
22 143941 Spring, Ext., .50" OD X .063" Wire
23 110751 Nut, Nylon Lock, 3/8-16
24 134431 Bolt, 5/16-18 X 1.5"
25 144091 Pulley, V-Belt, 2.625" OD, Idler
26 114921 Bracket, Belt Retainer
27 113071 Pulley, Flat Idler, 2-1/4"
28 101811 Washer, Lock, 1/4", Split, ZP
29 144511 Bolt, Carriage, 10-24 X .625"
30 143801 Clip, Inner, Lower Shield
31 180811 Washer, Lock, 3/8"
32 111551 Bolt, HHCS, 3/8-24 X .75", Gr. 2, ZP
33 145221 Screw, 3/8-16 X 1-1/2"
34 180131 Bolt, Tri Lobe, 1/4-20 x 1.0"
35 143851 Clamp, Battery
36 247491 Battery, 2.3 Ah, 12v
37 143861 Battery Pad
38 143791 Rod, Debris Guard
39 148231 Label, Safety Icons
40 234941 Label, Dr Logo, 6" Round, 4 Color
41 148221 Label, Head Rotation
42 127811 Label, Warning, Add Oil
43 136491 Label, Danger
