CALL TOLL FREE 1-800-DR-OWNER 41
End of Season and Storage
•
BEFORE PERFORMING ANY MAINTENANCE PROCEDURE OR INSPECTION, STOP THE ENGINE, WAIT
FIVE (5) MINUTES TO ALLOW ALL MOVING PARTS TO COME TO A COMPLETE STOP AND COOL.
DISCONNECT THE SPARK PLUG WIRE, KEEPING IT AWAY FROM THE SPARK PLUG.
•
NEVER STORE THE DR 13 HP CHIPPER WITH FUEL IN THE FUEL TANK INSIDE A BUILDING WHERE
IGNITION SOURCES ARE PRESENT, SUCH AS HOT WATER AND SPACE HEATERS, CLOTHES DRYERS
AND THE LIKE. IF YOU ARE GOING TO DRAIN THE FUEL TANK, DO THIS OUTDOORS. ALLOW THE
ENGINE TO COOL BEFORE STORING IN ANY ENCLOSURE.
•
WHEN NOT IN USE, YOUR DR 13 HP CHIPPER SHOULD BE STORED OUT OF THE REACH OF CHILDREN
AND IN A DRY LOCATION.
NOTE: Please refer to the Engine Owner's Manual for engine-specific procedures.
•
Change the oil (and oil filter, if applicable).
•
Remove the spark plug and pour about 1 ounce of motor oil into the cylinder hole. Reinstall the plug
and pull the recoil starter rope until you feel strong resistance (Manual Start model) or engage the
electric starter (Electric Start model) for a few seconds. This will coat the piston and seat the valves
to prevent moisture buildup.
•
Clean or replace the air filter(s).
•
Lubricate all grease fittings. See page 28.
•
Clean any dirt and debris from the cylinder head cooling fins, blower housing, debris screen, and
muffler area of the engine.
•
If your engine has a fuel filter, replace it.
•
If your DR 13 HP CHIPPER will be idle for more than 30 days, we recommend using a gas stabilizer.
This will prevent sediment from gumming up the carburetor. If there is dirt or moisture in the gas
or tank, remove it by draining the tank. Completely fill the tank with fresh, unleaded gas and add the
appropriate amount of stabilizer or gasoline additive. Run the engine for a short time to allow the
additive to circulate. Close the fuel Shut-Off Valve to prevent carburetor overflow and leakage.
•
Remove the battery or store your DR 13 HP CHIPPER in a dry environment where the temperature is
between –10° F (–23° C) and +85° F (+23° C). Make sure the storage temperatures will never be
outside these limits.
•
Check the Chipper Knife and Wear Plate for nicks and wear.
•
Check the Drive Belt for wear.
