Table 46. DIP Switch SW5 on Main PCBA
Switch
Setting
Note
SW5-1
Enable FSK data for SmartSeries systems
SW5-2
Enable 50 kHz VLC
SW5-3
Regenerate page line ground fault
SW5-4
Local ground fault activates output contact
SW5-5
Remote ground fault activates output contact
SW5-6
Local page audio activates output contact
SW5-7
Remote page audio activates output contact
SW5-8
Select T1 mode or E1 mode
Table 47. DIP Switch SW6 on Main PCBA
Switch
Setting
Note
SW6-1
Startup delay of echo cancellation training
SW6-2
Local party line off-hook regeneration
SW6-3
On-hook party line muting
SW6-4
Mute analog circuits
Table 48. T1/E1 Line Grounding on Main PCBA
Header
Setting
Note
P20
T1/E1
Line
receive
P21
T1/E1
Line
transmit
