RT-3020 User Guide
A-36
• Superior interference suppression (both in-band &
out-of-band)
• Patented multipath rejection
• 2 separate WAAS/EGNOS channels
• Self-survey mode (position averaging)
• Compact Physical Size
• CAN bus interface (RT-3020M Only)
• 1PPS output (RT-3020M Only)
• Event Marker input (RT-3020M Only)
Physical and Environmental
• Size (L x W x H): 8.18” x 5.67” x 3.06”
• Weight: 4lbs. (1.81 kg)
• External Power:
Input Voltage:
12 VDC nominal
(10VDC to 30VDC)
Consumption: < 10 W
• Connectors
I/O Ports:
2 x 7-pin LEMO
DC Power: 4-pin LEMO
SSR Antenna: BNC
GPS Antenna TNC
CAN bus/Event Marker: 5-pin LEMO
(RT-3020M Only)
1PPS Output: BNC
(RT-3020M Only)
• Temperature (ambient)
Operating:
-40º C to +55º C
Storage: -40º C to +85º C
• Humidity: 95% non-condensing
