GENERAL DESCRIPTION
The Model 204B BEVELMASTER™ is a Pipe Beveler designed for facing, beveling
and/or counterboring the ends of pipe or tubing in preparation for welding.
These machining operations may be performed either simultaneously or separately.
Pipe weld end preparations that meet all existing conventional codes including the
more stringent nuclear codes may be machined.
The various interchangeable jaw blocks and ramps will secure the Model 204B
BEVELMASTER™ to pipe and tubing having an inside diameter ranging from 1.25”
(31.8 mm) through 4.33” (110.0 mm).
The expanding mandrel provides fast, accurate self-centering and alignment to the
pipe or tubing to be machined.
The Model 204B BEVELMASTER™ accepts the reaction torque generated by the
machining operations through the mandrel.
No additional restraining devices are required.
