Termination and fail safe
(4-wire) Channel 1
14
6609-2211
Restore default settings
Channel 2
ON
1 2 3 4 5 6 7 8
S2
Normally in this position
ON
1 2 3 4 5 6 7 8
S2
Restore default settings.
Procedure:
Set and reboot, then
reset and reboot.
Port type
Channel 1
ON
1 2 3 4 5 6 7 8
S1
RS-422/485
ON
1 2 3 4 5 6 7 8
S1
RS-232
2- or 4-wire
Channel 1
ON
1 2 3 4 5 6 7 8
S1
4-wire, RS-422
ON
1 2 3 4 5 6 7 8
S1
2-wire, RS-485
Factory settings
ON
1 2 3 4 5 6 7 8
S2
Channel 2
ON
1 2 3 4 5 6 7 8
S1
Channel 1
ON
1 2 3 4 5 6 7 8
S1
Termination
and fail safe off
ON
1 2 3 4 5 6 7 8
S1
100
Ω
termination
between R+ and R–
Terminal open interpreted
as Mark (1)
Termination and fail safe
(2-wire) Channel 1
ON
1 2 3 4 5 6 7 8
S1
Termination
and fail safe off
ON
1 2 3 4 5 6 7 8
S1
100
Ω
termination
between T+ and T–
Terminal open interpreted
as Mark (1)
1
2
3
4
5
S1:1-8
Channel 1
S2:1-8
Channel 2 IC 2
Not used with RS-232
Not used with RS-232
Not used with RS-232
