www.ensembledesigns.com BrightEye 72 and 72-F - Page 14
3G/HD/SD SDI to HDMI Converter User Guide TM BrightEye 72 and 72-F
3G/HD/SD SDI Out
The SDI Out BNC provides reclocked loopback output of the input video signal. Connect this BNC to a
video destination such as a router, production switcher, or broadcast monitor.
3G/HD/SD SDI In
This BNC input accepts SD SDI, HD SDI, or 3 Gb/s HD SDI video signals with or without embedded
audio. The mapping of the first 8 channels of audio on the incoming SDI signal will pass through the
HDMI output.
Optical Input (BrightEye 72-F)
The BrightEye 72-F offers an optical input instead of the SDI input of the BrightEye 72. The optical
input accepts SD SDI, HD SDI, or 3 Gb/s HD SDI video signals with or without embedded audio. The
mapping of the first 8 channels of audio on the incoming optical signal will pass through the HDMI
output.
