www.ensembledesigns.com BrightEye 72 and 72-F - Page 30
3G/HD/SD SDI to HDMI Converter User Guide TM BrightEye 72 and 72-F
Serial Digital Output
Number One, loopback
Type Follows input
Delay < 5 μSec
Impedance 75 Ω
Return Loss >15 dB to 2.97 GHz
Max Cable Length 300 meters for 270 Mb/s
100 meters for 1.485 Gb/s
70 meters for 2.97 Gb/s
(Belden 1694A)
Analog Audio Output
Number One stereo pair
General Specifications
Size 5.625” W x 0.8” H x 5.5” D (143 mm x 20 mm x 140 mm)
including connectors
Weight 14 oz
Power 12 volts, 7 watts
(100-230 VAC modular power supply)
Temperature Range 0 to 40° C ambient (all specs met)
Relative Humidity 0 to 95%, non-condensing
Altitude 0 to 10,000 ft.
