Panasonic Toughpad FZ-A2 - Manual (Page 23)

23
Appendix
Specifications
This page provides the specifications for the basic model.
The specification is different according to the model number.
n Main Specifications
CPU Intel ® Atom™ x5-Z8550 Processor (2 MB *1 Cache, up to
2.4 GHz)
Video controller SoC embedded
Memory 4 GB *1
Storage Flash memory drive (eMMC) : 32 GB *2
Display Method 10.1 WUXGA type
Touchscreen 10 Finger touch (Capacitive)
Wi-Fi Intel ® Dual Band Wireless-AC 8260
Bluetooth *3 Version 4.2
Card Slot microSD Memory
Card Slot *4
microSDHC compatible
Interface Type-A USB port 3.0 × 1 *5 , Type-C USB port 3.1 x 1 *5 ,
HDMI output port x 1 *6 , Expansion Bus Connector, Headset
Jack (Miniature jack M3, CTIA standard / Audio output: 32
Ω, Output Power 4 mW × 2, Stereo / Microphone: Monaural
Input) x 1, Expansion bus connector (24 pin) x 1
Camera Front 1920 × 1080 dots, 30 fps (Video) / 1920 × 1080 dots (Still),
Array Microphone
Rear 1920 × 1080 dots, 30 fps (Video) / 3264 × 2448 dots (Still),
With camera light
Sensor Ambient light sensor, Magnetic sensor, Gyro sensor, Accel-
eration sensor
Power Supply AC adaptor or Battery pack
AC Adaptor *7 Input: 100 V to 240 V AC, 50 Hz/60 Hz, Output: 16 V DC,
4.06 A
Battery Pack Li-ion 11.4 V, Minimum 2600 mAh
(with CF-VZSU0QW)
Operating Time *8 Approx. 9 hours (models without wireless WAN), approx..
7.5 hours (models with wireless WAN)
Charging Time *9 Approx. 2.5 hours
Physical Dimensions (W × D × H)
(excluding projecting parts)
272 mm × 196 mm × 16.4 mm {10.71” × 7.72” × 0.65”}
Weight Approx. 880 g {Approx. 1.95 lb.} (with CF-VZSU0QW, ex-
cluding the optional devices)
Environ-
ment
Operating Temperature -10 °C to 50 °C {14 °F to 122 °F} (IEC60068-2-1, 2) *10
Humidity 30% to 80% RH (No condensation)
Storage Temperature -20 °C to 60 °C {-4 °F to 140 °F}
Humidity
30% to 90% RH (No condensation)
OS *11 Android 6.0
