February 5, 2008 UIM Instruction Manual 131
Installing the disk image on a replacement UIM
Installing the disk image on a replacement UIM
A replacement UIM may be used if your UIM has a hardware fault. The replacement
UIM is shipped with no operating system or UIM software installed. Use procedures
in this section to install the system disk image on the replacement UIM. You must use
the factory default image file located on the UIM Restore Program CD that you
received with your original UIM. Use the following flow chart as a guide.
Are you
installing the
disk image on
a replacement
UIM?
Refer to “Restoring
the system disk
image” on page 127 .
Proceed to “Part 1:
Preparing to install the
system disk image” on
page 132 .
Are you
replacing a
UIM-SAN-GEIP or
a UIM-DIS-GEIP?
Restoring the UIM
System Disk Image
Yes No
UIM-DIS-GEIP
Refer to Chapter 4,
UIM-SAN-GEIP
Installation: Grass
Valley Open SAN
System on page 49 .
Obtain a CVFS
client license for the
replacement SCSI
UIM from Thomson
Grass Valley
Product support.
Refer to:
Chapter 3,
UIM-DIS-GEIP
Installation:
Standalone Profile
UIM-SAN-GEIP
