60 UIM Instruction Manual February 5, 2008
Chapter 4 UIM-SAN-GEIP Installation: Grass Valley Open SAN System
For example:
192.168.100.157 SAN1_UIM1 SAN1_XP1_UIM SAN1_XP2_UIM
4. Use the following steps to type the entry for the UIM-SAN-GEIP 1000BT
streaming network interface
a. On a single line, enter the IP address for the network interface connected to the
streaming LAN.
b. Insert a few spaces, then type the UIM-SAN-GEIP host name followed by the
_he0 suffix. (NOTE: The suffix uses the zero character, not the letter ‘o’.)
For example:
192.168.200.157 SAN1_UIM1_he0
c. Insert a few more spaces, then type all Profile platform host names assigned to
this UIM-SAN-GEIP. Use the Profile host name followed by the _he0 suffix.
For example:
192.168.200.157 SAN1_UIM1_he0 SAN1_XP1_he0 SAN1_XP2_he0
5. If you modified the Profile XP platform host names as described in “Specify host
names in the Open SAN” on page 50 , you must revise those entries in the host file
now.
6. Save the master hosts file and exit Notepad.
7. Copy the new master hosts file to all network devices in the Open SAN system
including FSMs, Profile XP platforms, other UIM-SAN-GEIPs, and standalone
Profile platforms in the facility that proxy to the UIM.
c:\winnt\system32\drivers\etc\hosts
NOTE: Errors in this configuration step will render your media exchange network
inoperable. Take great care to enter all information correctly, then recheck for
errors.
