February 5, 2008 UIM Instruction Manual 93
Configure the UIM network settings
b. Right-click the Control Team - … Ports A & B, then select Properties to
configure network settings. Team descriptions are shown in the table that
follows.
NOTE: Always configure the Ethernet network settings using the fault tolerance
teams. Do not select and configure the network adapters directly. In non-redundant
Ethernet configurations, the unused ports will be ignored.
Intel 1000BT Port D LAN Enabled Intel(R) Pro/1000 MT Dual Port Server Adapter #2
Control Team - Intel
Ports A/B LAN Enabled Intel(R) Advanced Network Services Virtual Adapter
Streaming Team -
Intel Ports C/D LAN Enabled Intel(R) Advanced Network Services Virtual Adapter #2
Dell 1950
QLogic FC NIC LAN Enabled QLogic QLA2X00 PCI Adapter
Broadcom 1000BT
Port A LAN Enabled Broadcom BCM5708C NetXtreme II GigE (NDIS VBD
Client)
Broadcom 1000BT
Port B LAN Enabled Broadcom BCM5708C NetXtreme II GigE (NDIS VBD
Client) #2
Control Team -
Broadcom Ports A
and B LAN Enabled BASP Virtual Adapter
Intel 1000BT Port C LAN Enabled TEAM: Streaming Team - Intel(R) Pro/1000 MT Dual
Port Server Adapter
Intel 1000BT Port D LAN Enabled TEAM: Streaming Team - Intel(R) Pro/1000 MT Dual
Port Server Adapter #2
Streaming Team -
Intel Ports C and D LAN Enabled TEAM: Streaming Team
Connection Name Listed Description Configuration Tasks
QLogic FC NIC Fibre Channel Network Adapter Configure the IP Address,
subnet mask, and other
network settings for each
connection as required by
your network design and
site requirements. (Refer to
“Specify a subnet address
for the FC IP streaming
network” on page 83
.)
Contact your local network
administrator of details.
Control Team - … Ports A & B Control LAN Team Members a :
Primary: … 1000BT Port A
Secondary: … 1000BT Port B
a.
Primary designates the primary adapter for the team. Secondary designates the backup adapter. If the
primary connection is lost, then restored, it rejoins the team as a member and not the primary connection.
When redundant connections are not used, the unused port is ignored.
Name Type Status Device Name
