22
Setting Up the Kaleido-IP Multi-Viewer
Configuring Transport Streams 2
4. On the Configure menu, click Connect.
5. In Connect to Multi-viewer, enter the management IP address for the Kaleido-IP you wish to
configure.
The message “Connected to <IP address>” appears on the status bar.
6. Type the management IP address of your Kaleido-IP multi-viewer in the box, and then click OK.
The selected system’s hierarchical list appears in the main pane, showing the multi-viewer type,
system name and IP address, and the status bar shows the connection status.
Configuring Transport Streams
The default configuration for a Kaleido-IP system includes eight predefined multicast stream sources,
under NETWORK ADAPTER 2. Before you can use these sources, you must adjust their settings to match the
actual transport streams you wish to monitor. Depending on your monitoring purposes and Kaleido-IP
model, you may also need to add transport streams (see “Adding Stream Sources” on page 24). Refer to
“Managing Transport Streams in a Kaleido-IP System Representation” in the Kaleido-X User’s Manual, for
more information.
Modifying the Set of Predefined Stream Sources
To modify settings for a multicast transport stream source:
1. In the main window, click the System tab, and then click Description/Calibrations on the second level
tab bar.
2. Expand the System hierarchical list, and then navigate to the multicast transport stream source you
wish to configure, under NETWORK ADAPTER 2.
