24
Setting Up the Kaleido-IP Multi-Viewer
Adding Stream Sources 2
4. Repeat this until you have completed the required configuration changes to match the set of transport
streams you wish to monitor.
5. If there are default transport streams left, which you will not use, right-click them, and then click
Remove.
6. On the File menu, click Save. Alternatively, click the Save button on the toolbar.
Changes to the system are saved.
Adding Stream Sources
If you have the four-port Kaleido-IP model, or if you wish to monitor sources from Unicast streams, then
you need to add transport streams to the basic system configuration.
To add a multicast transport stream source:
1. In the main window, click the System tab, and then click Description/Calibrations on the second level
tab bar.
2. Expand the System hierarchical list, right-click the appropriate network adapter for the source you
wish to add, and then click insert Multicast stream.
Note: Under the network adapter elements, transport streams are listed in alphabetical order.
