Kaleido-IP
Quick Start Guide
27
2. In the Tools pane, expand the multi-viewer, and navigate to the transport stream for which you wish
to define logical sources.
3. Right-click the transport stream, and then click Create logical sources on the menu.
Logical sources are automatically created for every program signal found in the selected transport
stream.
4. Repeat until you have added logical sources for every stream you wish to monitor.
5. If your system involves a control panel from which you will control your multi-viewer as a router, then
configure source numbers for the KX Router logical router, by typing the appropriate numbers in the
first column (#) under Source info, and using the incremental copy tool as needed.
6. On the File menu, click Save. Alternatively, click the Save button on the toolbar.
Configuring Destinations
If your system involves a control panel from which you will control your multi-viewer as a router, then you
need to configure destinations for the KX Router logical router.
To configure the KX Router destinations:
1. In the main window, click the Destinations tab.
