Kaleido-IP
Quick Start Guide
25
The Multicast Stream Configuration window appears.
3. In Multicast Stream Configuration, replace the default source name if desired, select the appropriate
protocol (RTP, UDP), type the IP address and port number associated with the transport stream you
wish to add, and then click OK.
The Kaleido-IP establishes a connection with the selected source stream. All programs that are part of
the selected stream, and the elementary streams included in these programs, automatically appear
under the transport stream element in the System list.
4. Repeat this procedure until you have added all required multicast transport streams to your system
configuration.
5. On the File menu, click Save. Alternatively, click the Save button on the toolbar.
Changes to the system are saved.
To add a unicast transport stream source:
1. In the main window, click the System tab, and then click Description/Calibrations on the second level
tab bar.
2. Expand the System hierarchical list, right-click the appropriate network adapter for the source you
wish to add, and then click insert Unicast stream.
Notes
• With the current version of the Kaleido-X Software, it is preferable to use alphanumeric
characters (including the space character) only, for the transport streams’ source names.
• Under the network adapter elements, transport streams are listed in alphabetical order.
